SNBC Printer BTP-R180II USB+Serial+Ethernet
- Drivers Being Assaulted
- Driver Beiyang
- Driver Beiyang Btp-2002np
- Drivers Being Tailgated Are Advised
- Driver Being Charged In Motorcycle Accident
BEIYANG THERMAL PRINTER BTP-2002NP DRIVER - Don't show me this message again. See terms - opens in a new window or tab Other offers may be available from time to time. Got it, continue to print. See all condition definitions - opens in a new window or tab. To install the printer vertically on a wall, please obtain the optional wall mount system WMSNP from the. Beiyang btp-2200e win7 driver download November 7, 2019 by admin Select paper type according to the table as below: When the printer identifies that Auto checkout is needed, the printer shall feed two or three labels for checkout.
Includes Standard USB, Serial and Ethernet Interfaces
Item #: 132085
Options & Accessories
Product information
Setting the standard for value-class thermal receipt printers, SNBC delivers an affordable POS printer that provides all popular connection interfaces, including USB, Serial and Ethernet, with state-of-the-art speed and best-in-class reliability.
Drivers Being Assaulted
• Triple Interface Standard – USB, Serial and Ethernet
• Fast 230mm/Second Print Speed
• Simple Drop-In Paper Loading
• Standard Auto Paper Cutter
• Includes Serial and USB Cables and Power Supply
• Compatible with Popular POS Software Applications
Specifications
| Max Print Speed - Mono 80mm: | 230mm per Second |
| Max Print Speed - Gray Scale: | 150mm per Second |
| Max Print Speed - Two-Color: | 120mm per Second |
| Printing Method: | Direct Thermal |
| Resolution: | 180 DPI x 180 DPII |
Characters Per Line - Font A: | 42 (72mm) / 33 (58mm) 56 (72mm) / 45 (58mm)) |
| Characters Size - Font A: Font B: | 12 x 24 9 x 17 |
| Paper Roll Type - Width: Maximum Diameter: Paper Thickness: | 82 / 80 / 76 / 69 / 57mm ± 0.5mm 83mm 0.06mm ~ 0.08mm |
| Auto Paper Cutting Method: | Auto-Cutter with Selectable Full or Partial Cut |
| Reliability - MTBF: MCBF: Printhead Life: Cutter Life: | 360,000 Hours 60,000,000 Lines 150 Km 1,500,000 Cuts |
| Character Set - Alphanumeric: International: Code pages: | 95 13 56 Page |
| Bar Code - 1D: 2D: | UPC-A / UPC-E / EAN8 / EAN13 / Code39 / Code93 / CODE128 / CODABAR / ITF PDF417 / QR Code / Maxicode / GS1 |
| Interpreter: | ESC/POS |
| Interface: | Serial + USB + Ethernet |
Drivers - 32 bit: | Windows XP Prof. / XP Home / 2000 Server / 2000 Professional / POSReady 2009 |
| Drawer Port: | Up to 2 Drawers (+24VDC) / Drawer Compulsion |
| Data Buffer - Rec. Buffer RAM: RAM Bitmap: Flash Bitmap: | 64 KB 128KB 512KB |
| Power Supply: | AC 100 ~ 240 V, 50/60 Hz Adapter Included |
| Current/Power Usage: | 1.5A / 36W |
| Operating Temperature: | 40° ~ 114°F (5° ~ 45°C) |
| Operating Humidity: | 20% ~ 90% RH (Non-Condensing) |
| Dimensions: | 5-3/4'W x 5-9/16'H x 7-11/16'D |
| Shipping Weight: | 7 lbs. (Each Unit) / 30.10 lbs. (Master Carton of 4) |
| Safety and EMI: | FCC / RoHS |
| Windows Driver: | 32 and 64 bit Windows Driver - Win 10 Compatible |
| Printer Utility | Printer Utility |
PRINTER, BTP-2002NP
Item #: 132010
Driver Beiyang
Parts only
Options & Accessories
Product information
The BTP-2002NP thermal receipt printer is a low-cost high quality transaction printer produced by SNBC – a leading manufacturer of thermal print heads. The heavy-duty metal frame makes the BTP-2000NP thermal printer ideal for rugged environments.
Driver Beiyang Btp-2002np
• 200mm per Second Print Speed
• Drop and Print Paper Loading
• Serial, Parallel, USB, Ethernet and Wireless WiFi Interface Options
• Prints Watermark
• Stores and Prints Logo Images
• No Dip Switches – Intuitive Keypad Programming
• Extraordinary Reliability
• Certifi ed with Popular POS Software Applications
Drivers Being Tailgated Are Advised
Specifications
Driver Being Charged In Motorcycle Accident
| Max Print Speed: | 200mm per Second / 63 Lines per Second |
Characters Per Line - Font A: | 42 (80mm) / 37 (58mm) 56 (80mm) / 49 (58mm) |
| Characters Size - Font A: Font B: | 12 x 24 9 x 17 |
| Paper Roll Type - Width: Maximum Diameter: | 82.5±0.5mm, 80.0±0.5mm, 76.0±0.5mm, 69.5±0.5mm, 57.5±0.5mm 83mm |
| Reliability - MTBF: MCBF: Printhead Life: Cutter Life: | 348,000 Hours 52,000,000 Lines >_ 100 KM 1,500,000 Cuts |
| Character Set - Alphanumeric: International: Graphic: | 95 37 128 x 11 |
| Bar Code: | UPC-A / UPC-E / EAN8 / EAN13 / CODABAR / Code39 / ITF / Code128 / Code93 / PDF417 |
| Interpreter: | ESC/POS |
| Interface: | Serial / Parallel / USB / Ethernet / Wireless WiFi |
| Drivers: | Windows® POSReady 2009 / Windows 7 32 & 64 bit / Server 2008 32 & 64 bit / Vista 32 & 64 bit / Server 2003 32 & 64 bit / XP Professional 32 & 64 bit / 2000 Server / 2000 Professional |
| Drawer Port: | One RJ-11 (+24VDC) (Maximum 2 Drawers – Supports Open/Close) |
| Data Buffer - Rec. Buffer RAM: NV Bit Image Data: User NV Memory: | 4 KB RAM Selectable to 64 KB 128KB 1KB |
| Power Supply: | AC 100 ~ 240 V, 50/60 Hz Adapter Included |
| Current/Power Usage: | 2.5A / 60W |
| Operating Temperature: | 40° ~ 114°F (5° ~ 45°C) |
| Operating Humidity: | 20% ~ 90% RH (Non-Condensing) |
| Paper Cutting Method: | Auto-Cutter with Selectable Full or Partial Cut |
| Dimensions: | 5-3/4'W x 5-11/16'H x 7-5/8'D |
| Shipping Weight: | 8 lbs. |
| Safety and EMI: | FCC / RoHS |
| Windows Driver: | Windows Driver for 32 and 64 Bit o/s - windows 10 compatible |
| Printer Utility: | Printer Utility |
