Connect a single Mitutoyo digital gage
to an RS-232 serial port or USB port
The GageWay SM is an easy-to-use interface designed to connect a single Mitutoyo digital gage (calipers, micrometers, digital indicators, etc.), or Mitutoyo compatible output gages, to an RS-232 serial or USB port. When using the USB version of the GageWay SM, the USB connection looks like a standard RS-232 serial port to your PC application. Note: This is interface is not designed to send data into Excel. Purchase the GageWay KW for that feature.
Compare all GageWay interfaces.
Mitutoyo Drivers
Video, brochure and other resources can be found on the GageWay Videos & PDFs page.
Mitutoyo Comic-pci Driver
| GageWay SM with RS-232 Output This interface with RS-232 output is powered by the serial port and comes with a 9-pin serial cable built in. The standard cable lengths for this GageWay SM are 18 and 72 inches. The Users Guide is available as a PDF document. |
| GageWay SM with USB Output This interface with USB output is powered by the USB port and comes with a USB cable built in. To your PC application, this GageWay SM appears as a device connected to a serial port. The standard cable lengths for this GageWay SM are 18 and 72 inches. The Users Guide is available as a PDF document. |
GageWay SM Features
No baud rate or communication parameters required. The GageWay SM is pre-configured to operate at 9600-N-8-1. (USB driver installation may be required for USB version. Required Windows 2000 or later).
Standard lengths are 18 and 72 inches.
Supports Mitutoyo gages and any gage that provides a standard Mitutoyo output.
Standard Mitutoyo cables can be used without modification. These cables are available from any Mitutoyo dealer or can be purchased from MicroRidge.
Plugs directly into a standard 9-pin PC serial port or USB port.
Powered by the serial port or USB port. No external AC adapter is required.
Data output format set to gage measurement followed by a carriage return. No leading spaces are sent with the reading.
Initiate single and continuous gage readings with the read button on the gage, an optional foot switch or hand switch, or a simple computer command. The optional foot or hand switch plugs into a connector on the side of the GageWay SM.
LED flashes when a gage reading has been obtained.
Firmware (software in the GageWay SM) can be upgraded via the serial or USB port. Check our Products Downloads page for updates.
Includes ComTestSerial communications test program.
If you are using CDI or Federal gages with a Mitutoyo output, you may need to purchase the gage cables from MicroRidge.
Control gage functions by easy-to-use computer commands.
Transmit gage data in excess of 100' via the RS-232 connection. This allows you to position your gage at extended distances from your PC. (RS-232 version only)
